Foto | Modelo | DN(mm) | Rated Flow(m³/h) | Rated Head(m) | Max. Head(m) | Voltage(V) | Frequency(Hz) | Power(W) | Port-to-port length(mm) | Pipe connection/Flange |
---|---|---|---|---|---|---|---|---|---|---|
![]() |
Master H 25-7.5 | 25 | 2.2 | 4.7 | 7.5 | 220~240 | 50/60 | 60 | 130/180 | G 1 1/2 |
![]() |
Master H 32-7.5 | 32 | 2.2 | 4.5 | 7.5 | 220~240 | 50/60 | 60 | 180 | G 2 |
![]() |
Master H 20-9 | 20 | 2.5 | 6.5 | 9 | 220~240 | 50/60 | 95 | 130 | G 1 |
![]() |
Master H 25-9 Pro | 25 | 2.5 | 6.5 | 9 | 220~240 | 50/60 | 95 | 130/180 | G 1 1/2 |
![]() |
Master H 32-9 | 32 | 2.5 | 6.5 | 9 | 220~240 | 50/60 | 95 | 180 | G 2 |
![]() |
Grand 25-11 Pro | 25 | 3.5 | 7.5 | 11 | 220~240 | 50/60 | 140 | 130/180 | G 1 1/2 |
![]() |
Grand 32-11 | 32 | 3.5 | 7.5 | 11 | 220~240 | 50/60 | 140 | 180 | G 2 |
![]() |
Grand 25-17 | 25 | 5 | 13 | 17 | 220~240 | 50/60 | 350 | 180 | G 1 1/2 |
![]() |
Grand 32-17 | 32 | 5 | 12.5 | 17 | 220~240 | 50/60 | 350 | 180 | G 1 1/2 |
![]() |
GPA III Pro Z197 | 15 | 1 | 6 | 7.5 | 230 | 50/60 | 60 | / | / |
![]() |
GPA III Pro Z107 | 15 | 1 | 6 | 7.5 | 230 | 50/60 | 60 | / | / |
![]() |
GPA III Pro Z178 | 15 | 1 | 6 | 7.5 | 230 | 50/60 | 60 | / | / |
![]() |
GPA III Pro Z106 | 15 | 1 | 6 | 7.5 | 230 | 50/60 | 60 | / | / |
![]() |
GPA III Pro Z027 | 15 | 1 | 6 | 7 | 230 | 50/60 | 60 | / | / |
![]() |
GPA III Pro Z108 | 15 | 1 | 6 | 7.5 | 230 | 50/60 | 60 | / | / |
![]() |
Z178 | 15 | 2 | 4 | 7 | 230 | 50 | 32/40/55/90 | / | / |
![]() |
Z108 | 15 | 2 | 4 | 7 | 230 | 50 | 32/40/55/90 | / | / |
![]() |
Z106 | 15 | 2 | 4 | 6.5 | 230 | 50 | 32/40/55/90 | / | / |
![]() |
Z027 | 15 | 2 | 4 | 7 | 230 | 50 | 32/40/55/90 | / | / |
![]() |
Basic Pro 32-12S | 32 | 6 | 8 | 12 | 230 | 50 | 500 | 180/220 | G2- G1 1/2 or G2- G1 1/4 |
![]() |
Basic Pro 32-12SF | 32 | 6 | 8 | 12 | 230 | 50 | 500 | 220 | DN32 – G2 |
![]() |
Basic Pro 32-9SF | 32 | 5 | 6.5 | 9 | 230 | 50 | 300 | 220 | DN32 – G2 |
![]() |
Basic Pro 32-9S | 32 | 5 | 6.5 | 9 | 230 | 50 | 300 | 180/220 | G2- G1 1/2 or G2- G1 1/4 |
![]() |
Basic Pro 25-12S | 25 | 3.5 | 9 | 12 | 230 | 50 | 300 | 200 | G1 1/2-G1 |
![]() |
Instant E 15-1.5 | 15 | / | / | 1.4 | 230 | 50 | 28 | 85 | G3/4 |
![]() |
Basic 20-4S | 20 | 2 | 9.5 | 12 | 115/230 | 50/60 | 270/240/160 | 130/150 | G1 |
![]() |
Basic 25-4SB | 25 | 1.6 | 2.6 | 4 | 115/230 | 50/60 | 65/50/32 | 130 | G1 1/2 |
![]() |
Basic 25-4S | 25 | 1.6 | 2.6 | 4 | 115/230 | 50/60 | 65/50/32 | 130/180 | G1 1/2 |
![]() |
Basic 32-4S | 32 | 1.8 | 2.6 | 4 | 115/230 | 50/60 | 65/50/32 | 180 | G2 |
![]() |
Basic 20-5S | 20 | 1.8 | 3.2 | 5 | 115/230 | 50/60 | 85/60/40 | 130/150 | G1 |
